Intermatic CD1-024R Compressor Defender Protects Central Air Conditioner / Heat Pump Compressors and Circuit Boards
14 sold in last 24 hours
- Surge, brownout and short cycle protection with 120, 208 and 240 VAC loads
- LED indicators provide real-time status updates for quick and easy troubleshooting
- Auto-sense voltage technology 120-240 VAC universal input voltage
- Meets ANSI/UL 1449 3rd edition requirements
- UL listed for safety
Tags |
Estimated shipping
Select a product to estimate shipping.Power disturbances damage air conditioner compressors without warning. Let the Compressor Defender by Intermatic take the hit so air conditioners are never interrupted. The all-in-one Compressor Defender device protects compressors and circuit boards in residential and light commercial applications from brownouts, surges and short cycles. The protective device can be installed inside a condensing unit or on an outdoor compressor. LED indicators provide real-time status updates for quick and easy troubleshooting. Compliant with AHRI Standard 110-1012 Range B2 for voltage drop protection. Specifications: 120-240 VAC Single Phase 60 Hz | Normally Closed Relay 24 VAC | Type 2 SPD | Control Output Current Rating: 2A @ 24 VAC, isolated N.C. contact | Voltage Protection Rating: L-N/G: 700, L-L: 1200 | Nominal Discharge Rating: In (10 kA) |Max Continuous Over-Voltage (MCOV): L-N/G: 150V, L-L: 300V | Short Circuit Current Rating: 20kA | Under-Voltage Response Time: 3 line cycles |Operating Temp: -40°F to 158°F (-40°C to 70°C).
| Main Specification | |
|---|---|
| Fremstiller | Intermatic |
| Enhedstælling | 1 Antal |
| Aktuel bedømmelse | 20 Kiloamps |
| Mærke | Intermatic |
| UPC | 078275142923 |
| Antal elementer | 1 |
| Kredsløbstype | Standard |
| Inkluderede komponenter | CD1-024R |
| Produktdimensioner | 5"D x 3"W x 8.01"H |
| Spænding | 240 Volt |
| Globalt handelsnummer | 00078275142923 |
| Monteringstype | Nipple mounting |
| Vægt | 1,2 pounds |
| Product information | |
| EU Reservedelsvarighed | 3 År |
| Technical Details | |
| Delnummer | CD1-024R |
| Model | CD1-024R |
| Antal polakker | 1 |
| Item details | |
| Varetype Navn | Intermatic CD1-024R Compressor Defender Protects Central Air Conditioner / Heat Pump Compressors and Circuit Boards |
| Measurements | |
| Varens dimensioner D x W x H | 5"D x 3"W x 8.01"H |
| Others | |
| Produkttype | Intermatic CD1-024R Compressor Defender Protects Central Air Conditioner / Heat Pump Compressors and Circuit Boards |
